- Applied Ballistics on board: with new GPS tracking feature LPT™ (Leica ProTrack) for target guidance, and numerous additional functions
Downloads
Order Number | 40809 | |
Delivery Scope | Contoured Neoprene carrying strap, front lens cover, eyepiece caps, Cordura case, battery | |
Magnification | 8x | |
Front lens diameter | 32mm | |
Exit pupil | 4mm | |
Twilight factor | 16 | |
Field of view at 1,000 yds / 1,000 m | 405 ft. / 135 m | |
Field of view for spectacle wearers | > 392 ft. / > 131 m | |
Eye-relief | 16mm | |
Objective angle of view | 7° | |
Close distance | approx. 16 ft. / 5 m | |
Light transmission | 91% | |
Diopter compensation | ± 4 dpt | |
Distance Measurement: Range | 10 up to approx. 2,500 yds / 2,300 m | |
Distance Measurement: Equivalent Horizontal Range (EHR) | 10 up to approx. 1,200 yds / 1,100 m | |
Correction output with Applied Ballistics Ultralight (default setting) | max. 875 yds / 800 m | |
Correction output with Applied Ballistics Elite (upgrade) | max. 2,500 yds / 2,300 m | |
Distance Measurement: Accuracy | ±0.5 m at 10-200 m / 0.5 yds at 10-219 yds ±1.0 m at 200-400 m / 1.0 yds at 219-438 yds ±0.5 % above 400 m / 0.5 % above 438 yds | |
Distance Measurement: Measuring time | max. approx. 0.3 s | |
Distance Measurement: Measuring modes | Scanning mode, single measurement | |
Switchover meter / yards | yes | |
Ballistic function | yes | |
On-board wind correction | yes | |
Output "equivalent horizontal range" | yes | |
Output "Unit correction" for elevation and windage | yes | |
Output "Click correction" for elevation and windage | yes | |
Applied Ballistics Ultralight on-board | yes | |
Bluetooth interface | yes | |
Connect to Leica ballistics app | yes | |
Use customized ballistic profiles | yes | |
Upgradeable to Applied Ballistics Elite | yes | |
BaseMap | yes | |
Kestrel / Garmin connection | yes | |
GPS guide LPTTM (Leica ProTrack) | yes | |
Display | LED display with 4 digits, easily legible in any light | |
Eyepiece for eyeglass wearers | yes | |
Eyecups | yes, rotary sliding sleeve, detachable, with 4 click-stops | |
Prism system | Perger-Porro system | |
Lens coating | HDC multilayer coating, AquaDura coating | |
Focusing | Internal focusing via central drive | |
Laser | Eye-safe invisible laser according to EN and FDA class 1 | |
Laser beam divergence | 1.2 x 0.5 mrad | |
Barometric pressure sensor | yes | |
Temperature sensor | yes | |
Temperature measurement | yes | |
Angle sensor | yes | |
Compass | yes | |
First destination logics | no | |
Battery | 1 x 3 V / Lithium-type C2R | |
Battery lifetime | approx. 2,000 measurements at 20 °C / 68 °F | |
Watertightness | Watertight to a depth of 16 ft / 5 m | |
Housing | Magnesium, nitrogen-filled | |
Dimensions (W x H x D) | 4.6 x 6.0 x 2.8 inch / 117 x 153 x 70 mm | |
Weight | approx. 28.9 oz / 820 g (without battery) | |
Accessories | - (42 163)- (42 220) |
