91920574
Camera type: | Compact digital rangefinder system camera with black-and-white sensor | |
Lens mount: | Leica M bayonet with additional sensor for 6-bit coding. | |
Lens system: | Leica M lenses from 16 to 135 mm. | |
Image sensor: | Active area approx. 23.9 x 35.8 mm, 5212 x 3468 pixels (18 megapixels). Infrared filter for non-visible spectrum over 700nm, no low-pass filter | |
Resolutions: | Adjustable, DNG™: 5212 x 3468 (18 megapixels), JPEG: 5216 x 3472 (18 megapixels), 3840 x 2592 (10 megapixels), 2592 x 1728 (4.5 megapixels), 1728 x 1152 (2 megapixels), 1280 x 864 (1 megapixel).
| |
Data formats: | DNG™ (raw data), uncompressed, JPEG with quality-oriented compression | |
File sizes: | DNG™: 18 MB (compressed), 36 MB (uncompressed), JPEG: approx. 2–10 MB.
| |
Color spaces: | sRGB preset | |
Storage media: | SD cards up to 2 GB, SDHC cards up to 32 GB. | |
Menu languages: | German, English, French, Spanish, Italian, Japanese, Traditional Chinese, Simplified Chinese, Russian. | |
Exposure metering: | Through the Lens (TTL) metering, center-weighted with variable aperture. Center-weighted TTL metering for flash exposure with system-conformant SCA-3000/2 standard flash units. | |
Metering range: | With aperture 1.0 / ISO 320/26°: EV 1 to 21 Flashing of the left-hand triangular LED in the viewfinder indicates that the brightness reflected is below the metering range. | |
Sensitivity range: | ISO 320/26° to ISO 10000/41°, adjustable in 1/3-ISO stages, with automatic timer (A) and manual exposure setting, optionally automatic control or manual adjustment. ISO 160 additionally available as pull function. | |
Exposure modes: | Automatic timer (A) / Manual (M) | |
Flash unit attachment: | Via accessory shoe with center and control contacts. | |
Synchronisation: | Optionally triggered at the first or second shutter curtain. | |
Flash sync time: | = 1/180 s; slower shutter speeds usable. | |
Flash exposure metering: | Control with center-weighted TTL pre-flash metering (with SCA- 3501/3502 adapter, or SCA-3000 standard flash unit such as Leica SF 24D/Leica SF 58). | |
Flash measurement cell: | Two silicon photo diodes with collection lens on the camera bottom. | |
Flash exposure Compensation: | ±3 1/3-EV in 1/3-EV stages adjustable at SCA-3501/3502 adapter. On the Leica SF 24D with computer control it is possible to program ±3 EV in 1/3-EV stages, or from 0 to -3 EV in 1-EV stages; on the Leica SF 58 ±3 EV can be programmed in 1/3-EV stages in all modes. | |
Displays in flash mode: | Ready: By the flash symbol LED in the viewfinder being constantly lit; confirmation of success: By the LED remaining lit or flashing rapidly for a while after taking the picture; underexposure display by the LED going out for a while. | |
Viewfinder principle: | Large, light bright-line rangefinder with automatic parallax compensation. | |
Eyepiece: | Adjusted to -0.5 dpt. Corrective lenses from -3 to +3 dpt. available. | |
Image field limiter: | By activating two bright lines each: For 35 and 135 mm, for 28 and 90 mm or for 50 and 75 mm. Automatic activation when lens is screwed in. Any desired pair of bright-line frames can be activated using the image field selector. | |
Parallax compensation: | The horizontal and vertical difference between the viewfinder and the lens is automatically compensated according to the relevant distance setting, i.e. the viewfinder bright-line automatically aligns with the subject detail recorded by the lens. | |
Matching viewfinder & actual image: | The bright-line frame size at a range setting of 1 metre corresponds exactly to the sensor size of approximately 23.9 x 35.8 mm. At an infinity setting, depending on the focal length the sensor captures more than the relevant bright-line frame shows and, conversely, at ranges below 1 metre somewhat less. | |
Magnification: | (With all lenses) 0.68 times. | |
Large-basis Rangefinder: | Split or superimposed image range finder shown as a bright field in the center of the viewfinder image. | |
Effective metering basis: | 47.1 mm (mechanical metering basis 69.25 mm x viewfinder magnification 0.68 times). | |
In the viewfinder: | LED symbol for flash status (at bottom). Four-digit seven-segment LED digital display, brightness adapted to ambient conditions, for: Warning in case of exposure correction; display of automatic shutter speed in automatic mode; advisory indicating use of metering memory lock LED exposure monitor with two triangular and one central circular LED with manual exposure setting. | |
Displays on the back: | 2.5" monitor (color TFT LCD) with 230,000 pixels | |
Shutter: | Microprocessor-controlled, ultra-quiet metal leaf slotted shutter with vertical movement. | |
Shutter speeds: | In automatic mode (A) steplessly from 32 s to 1/4000 s. Using manual setting 8 s to 1/4000 s in half steps, B for long exposures up to max. 240 s 1/180 s fastest shutter speed for flash synchronization. | |
Series exposures: | Approx 2 pictures/s, <- 8 pictures in series. | |
Shutter release: | Three-stage: Exposure metering on – Metering memory lock (in aperture priority mode) – Shutter release. Integrated standard cable release thread. | |
Self-timer: | Delay optionally 2 (aperture priority and manual exposure setting) or 12 s (menu setting), indicated by flashing LED on front of camera and corresponding display on the monitor. | |
Turning the camera on/off: | By main switch on camera cap; optionally automatic shutdown of camera electronics after approx. 2/5/10 minutes; reactivated by tapping the shutter release. | |
Power supply: | One lithium-ion rechargeable battery, rated voltage 3.7 V, capacity 1900 mAh. Capacity display in monitor; with shutter held open (for sensor cleaning) additional acoustic warning of low capacity. | |
Battery charger: | Inputs: 100-240 V AC, 50/60 Hz, automatic switching, or 12/24V DC; Output: 4.2 V DC, 800 mA. | |
Camera body Material: | All-metal case made of die-cast magnesium; synthetic leather covering. Cap and base plate made of brass, black chrome finish, sapphire glass monitor cover.\. | |
Tripod thread: | A 1/4 (1/4 “) DIN, stainless steel, integrated in base plate | |
Operating conditions: | 0 to +40°C | |
Interface: | 5-pin Mini-USB 2.0 high-speed port for fast data transfer | |
Dimensions (WxDxH): | Approx. 139 x 37 x 80 mm (5.5” x 1.5” x 3.2”) | |
Weight (with battery): | 600 g. (1.32 lbs.) | |
Software licenses Supplied: | Adobe Lightroom, Nik Collection Software Suite, as download versions (highspeed internet connection required) | |
Package contents: | 100 - 240 V charger with two power cables (EU, USA; some export markets differ) and one vehicle charging cable; lithium-ion battery; USB cable; real-leather carrying strap; original Leica Monochrom print of a campaign motif; user manual; information material for registration and software downloading | |
Compatibility: | Windows® 7 SP1, Windows® Vista® SP2, Windows XP SP2, Mac® OS X 10.6.8 (Snow Leopard) or higher. |
